Welding Impeller C.P.M. Stainless Steel Submersible Pump / S.S. Centrifugal Pump
Self Priming Pump APPLICATIONS
1. Water Pump domestic application such as pool suction.
2. Agricultural irrigation
3. Garden and farm irrigation
4. Lowering the underground water level
5. Various industrial applications
6. An automatic water supply system
Self Priming Pump STRUCTURAL CHARACTERISTICS
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Stainless Steel | |
| Impeller | Brass | Noryl P.P.O. |
| Motor housing | Aluminum | |
| Stator&Rotor | 1.Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire |
| Front cover | Cast Iron | |
| Bearing | Chinese Best Quality Bearing | NSK, S.K.F., or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| Thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventil on | |
| Max. Suction li t | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC |
TECHNICAL DATA
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) |
| SCM-18ST | 0.5 / 0.37 | 2.5 | 2850 | 110 | 18 | 9 | 1.25"x1" | 390x220x270 | 12 |
| SCM-20ST | 0.75 / 0.55 | 3.8 | 2850 | 130 | 20 | 9 | 1.25"x1" | 390x220x270 | 12.5 |
| SCM-26ST | 1 / 0.75 | 5.2 | 2850 | 145 | 26 | 9 | 1.25"x1" | 390x220x270 | 13.5 |
| SCM-34ST | 1.5 / 1.1 | 7 | 2850 | 190 | 34 | 9 | 1.25"x1" | 400x260x330 | 24 |
Other voltages and frequencies available on request
Self Priming Pump ADVANTAGE
100% high-quality copper,100% output
Cold-rolled silicon steel sheet by a high-speed punching machine
Good quality bearing, the surface more smooth, the dimension more precise
Thermal protector
One year warranty
Self Priming Pump GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Self Priming Pump OUR SERVICE
1. Directly fact ry sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. We provide one-stop services for all goods produced by ourselves, from designing printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to makeF.A.Q.e products customers. O.Q.o customers' target priWhat'sFAQ
1. Q: What's the M.O.Q.?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are an m manufacturer.
3O.E.M.: Can you accept using our logo?
A: Yes, we can o O.E.M. for you.
4. Q: How can I get the pump?
A: Usually we suggest express for samples. If the volume reaches 1m³, the Seaway illWhat'stter.
5. Q: What's the warranty period?
A: 1 year.
