Centrifugal Pump Stainless Steel Water Pump For Water Tower 0.75HP
Self Priming Pump Working Condition
Max. fluid temperature +60℃
Max. ambient temperature +40℃
Max. solid impurity:0.1%,Max. particle size: 0.2mm.
Self Priming Pump
Pump Body: Stainless steel
Impeller: Brass/P.P.O
Mechanical Seal: Carbon/Ceramic/Stainless steel
Motor
Single Phase
Heavy-Duty Continuous Work
Motor Housing: Aluminum
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation
Construction and safety standards in compliance with I.E.C.
220V/50HZ.60HZ 110V/50HZ.60HZ 220v.110v/50hz.60hz is available on request.
Self Priming Pump Application:
1. Single impeller centrifugal pumps, extremely silent suitable for household, civil and industrial applications
2. Agricultural irrigation
3. Apply to water supply and drainage of urban
4. Lowering the underground water level
5. Various industrial applications.
6. Water circulating refrigeration or central heating
Self Priming R.P.MTechnical Data:
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) |
| SCM-20ST | 0.75 / 0.55 | 3.8 | 2850 | 130 | 20 | 9 | 1.25"x1" | 390x220x270 | 12.5 |
Other voltages and frequencies available on request
Self Priming Pump Advantages:
1. Motors made to heavy-duty service factors
2. Can be made with stainless steel shaft
3. Others insulation on request
4. High performance and efficiency
5. Heavy-duty ball bearings
Self Priming Pump Structural Characteristics:
| Main Specification | Standard | Optional |
| TransmisP.P.O.n medium | Clean Water | |
| Pump body | Stainless Steel | |
| Impeller | Brass | Noryl P.P.O. |
| Motor housing | Aluminum | |
| Stator&Rotor | 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality coppS.K.F.wire |
| Front cover | Cast Iron | |
| Bearing | Chinese Best Quality Bearing | NSK, S.K.F., or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| Thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| CI.E.C.ect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with I.E.C. |
Self Priming Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Self Priming Pump Our Service:
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. We provide one-stop services for all goods produced by ourselves, from designing printing to processing. Customers can provide the design according to your requF.A.Q. and samples makinM.O.Q.also we can advise how to make the products according to customers' target prices.
F.A.Q.
1. Q: What's the M.O.Q.?
A: Trial sample order is ok.
2. Q: Are you a facO.E.M.y or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do O.E.M. for you.
4. Q: How can I get the pump?
A: Usually, we suggest we express for samples. If the volume reaches one m³, the Seaway will be better.
5. Q: What's the warranty period?
A: 1 year.
