Stainless Steel J.E.T. Centrifugal Water Pump With Stainless Steel Pump Body
Self Priming Pump Descriptions:
JET-ST series self-priming pumps are highly efficient jet pumps with excellent suction, even air bubbles. The pump consists of a single impeller, centrifugal pump, and jet pipe with a nozzle. The pump body is made of stainless steel, the impeller can be made of P.P.O., brass, or stainless steel, the diffuser is made of P.P.O., and the shaft is in stainless steel, which makes the pumps more particularly suitable for water supplying in domestic installations, small-scale agriculture watering and where self-priming operation is demanded, especially for home drinking water filling and garden irrigating.
Technical data:
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| JETST-130L | 1 / 0.75 | 5.2 | 2850 | 62 | 45 | 9 | 1"x1" | 420x220x230 | 12 |
Other voltages and frequencies available on request
Self Priming Pump Advantages:
1 Used screwed suction and discharge, quick and easy installation.
2. Self-priming jet assisted centrifugal pump provides higher pressure and good suction ability
3. Cold-rolled silicon steel sheet by high-speed punching machine
4. Pump body and impeller and so on made of stainless steel, ejector made of plastics with high intensity and abrasion-proof
5. Motor corrosion-resistant and excludes dust and dirt. It is protected against high operating temperature and high current by a built-in automatically resetting thermal overload.
6. Thermal protector
7. Strictly and Perfect Management is Guaranteed For Production.
Applications
| Residential Bungalows |
| Community Water Supply C |
| construction Site | |
| Apartment | |
| Small Farms | |
| Lawns & Gardens | |
| Car Washing | |
| Sprinklers | |
| Hotels & Hospitals |
Self Priming Pump Structural Characteristics:
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Stainless steel | |
| Impeller | Brass | Noryl P.P.O., stainless steel |
| Motor housing | Aluminum | |
| Stator&Rotor | 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire |
| Front cover | Cast Iron | |
| Bearing | Chinese Best Quality Bearing | NSK, S.K.F., or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| Thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with I.E.C. |
guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Self Priming Pump our service
1). We are happy that the customer has given us some suggestions for price and products.
2). If you have any questions, please let us know first by E-mail or Telephone. We can deal with them for you in time.
3). Offer our customers the lowest prices. Streamline the buying and paying processes.
4). Deliver goods to our customers worldwide with speed and precision.
5). Ensure the excellent quality of our products.
6).12 months FREE warranty.
7). Accept O.E.M.
Self Priming Pump F.A.Q.
1). Q: How about the M.O.Q.?
A: Usually, it is 50 P.C.S. for each model.
2). Q: Are you a factory or a trading company?
A: We have made water pumps, motors, alternators, and diesel generators since 2006.
3). Q: Can you accept to use our logo?
A: Yes, we can. Any O.E.M.s are welcome!
4). Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.
5). Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.
6). Q: How about the warranty?
A: 1 year from shipped on board date.
